Product Summary

The RC28F128J3D75 Embedded Flash Memory J3 Version D (J3 v. D) provides improved mainstream performance with enhanced security features, taking advantage of the high quality and reliability of the NOR-based Intel* 0.13 μm ETOX VIII process technology. Offered in 128-Mbit (16-Mbyte), 64-Mbit, and 32-Mbit densities, the RC28F128J3D75 brings reliable, low-voltage capability (3 V read, program, and erase) with high speed, low-power operation. The RC28F128J3D75 takes advantage of the proven manufacturing experience and is ideal for code and data applications where high density and low cost are required, such as in networking, telecommunications, digital set top boxes, audio recording, and digital imaging. Numonyx Flash Memory components also deliver a new generation of forward-compatible software support. By using the Common Flash Interface (CFI) and Scalable Command Set (SCS), customers can take advantage of density upgrades and optimized write capabilities of RC28F128J3D75.

Parametrics

RC28F128J3D75 absolute maximum ratings: (1)Temperature under Bias Expanded (TA, Ambient): –40 to +85 ℃; (2)Storage Temperature: –65 to +125 ℃; (3)VCC Voltage: –2.0 to +5.6 V; (4)VCCQ: –2.0 to +5.6 V; (5)Voltage on any input/output signal (except VCC, VCCQ): –2.0 to VCCQ (max) + 2.0 V; (6)ISH Output Short Circuit Current: 100 mA.

Features

RC28F128J3D75 features: (1)Architecture: High-density symmetrical 128-Kbyte blocks, 256 Mbit (256 blocks), 128 Mbit (128 blocks), 64 Mbit (64 blocks), 32 Mbit (32 blocks); (2)Performance: 75 ns Initial Access Speed (128/64/32-Mbit densities), 95 ns Initial Access Speed (256 Mbit only), 25 ns 8-word and 4-word Asynchronous page-mode reads, 32-Byte Write buffer, 4 μs per Byte Effective programming time; (3)System Voltage and Power: VCC = 2.7 V to 3.6 V, VCCQ = 2.7 V to 3.6 V; (4)Packaging: 56-Lead TSOP package (32, 64, 128 Mbit; (5)only), 64-Ball Numonyx Easy BGA package (32, 42, 128 and 256 Mbit).
