Product Summary
The HD63B50FP Asynchronous communications Interface Adapter provides the data formating and control to interface serial asynchronous data commounications information to bus organized systems. The bus interface of the HD63B50FP includes select, enable, read/writer, interrupt and bus interface logic to allow data transfer over an 8-bit bi-direational data bus. The parallel data of the bus system of the HD63B50FP is serially transmitted and received by the asynchronous data interface with proper formating and error checking.
Parametrics
HD63B50FP absolute maximum ratings: (1)supply voltage: -0.3 to +7.0 V; (2)input voltage: -0.3 to +7.0 V; (3)maximum output current: 10 mA; (4)operating temperature: -20 to +75 ℃; (5)storage temperature: -55 to +150 ℃.
Features
HD63B50FP features: (1)serial/parallel conversion of data; (2)seven and eight-bit transmission; (3)optional even and odd parity; (4)parity, overrun and framing error checking; (5)perpheral/modem control functions; (6)low-power, high-speed, high-desity CMOS; (7)compatible with NMOS ACIA; (8)wide range operating voltage (VCC=5V±10%); (9)up to 1 Mbps transmission.
Diagrams
 |
