Product Summary
The ICM7555MTV is a respectively single and dual general purpose RC timer capable of generating accurate time delays or frequencies. The primary feature is an extremely low supply current, making this device ideal for battery-powered systems. Additional features include low THRESHOLD, TRIGGER, and RESET currents, a wide operating supply voltage range, and improved performance at high frequencies.And it is used in pulse generator,precision timing,time delay generation and so on.
Parametrics
ICM7555MTV absolute maximum ratings: (1)Supply Voltage:+18 V; (2)Output Current:100mA; (3)Power Dissipation:200mA; (4)Operating Temperature Range:-55°C to +125°C; (5)Storage Temperature:-65°C to +150°C; (6)Lead Temperature (Soldering 60 Seconds): +300°C.
Features
ICM7555MTV features: (1)Improved 2nd Source; (2)Wide Supply Voltage Range: 2-18V; (3)No Crowbarrlng of Supply During Output Transition; (4)Adjustable Duty Cycle; (5)Low THRESHOLD, TRIGGER and RESET Currents; (6)TTL Compatible; (7)Monolithic, Low Power CMOS Design.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 ICM7555MTV |
Maxim Integrated Products |
Timers & Support Products |
Data Sheet |
Negotiable |
|
||||
|
ICM7555MTV/HR |
Maxim Integrated Products |
Timers & Support Products |
Data Sheet |
Negotiable |
|
||||
