Product Summary
The JANTXV2N5685 is a silicon controlled rectifier.
Parametrics
JANTXV2N5685 absolute maximum ratings: (1)Collector-emitter voltage, VCEO: 60V; (2)Collector-base voltage, VCBO: 60V; (3)Emitter-base voltage, VEBO: 5.0V ; (4)Base current, IB: 15A ; (5)Collector current, IC: 50A; (6)Total power dissipation: at TC= +25℃, PT: 300W; at TC= +100℃ PT: 171W; (7)Operating & storage junction temperature range, TJ, Tstg: -55 to +200℃.
Features
JANTXV2N5685 features: (1)Collector-emitter breakdown voltage, IC= 100mAdc, V(BR)CEO: 60V; (2)Collector-emitter curoff current, VCE= 30V, ICEO: 500μAdc; (3)Collector-emitter curoff current, VCE= 30V, VBE= 1.5V, ICEX: 500μAdc; (4)ollector-base curoff current, Vcb= 60V, ICBO: 2.0mAdc.
