Product Summary
The SAA1027 is a TUBE Stepper motor driver which is intended for driving a four phase two stator stepper motor.The circuit consists of four output stages, a logic part and three input stages.The logic part is driven by three input stages; a trigger input stage, an input stage which can change the switching sequence of the logic part so that the motor can rotate clock wise (CW) or counter clock wise (CCW) and a set input stage to set the four output stages. The three inputs are compatible with high noise immunity logic to ensure proper operation, even in noisy environments.
Parametrics
SAA1027 absolute maximum ratings: (1)Voltages:Supply voltage:20V;Input voltage:20V; (2)Output current:500mA; (3) Storage temperature:-40°C to +125°C; (4)Operating ambient temperature:-20°C to 70°C.
