Product Summary
The RTC-64613A is an 8-bit real time clock module.
Parametrics
RTC-64613A absolute maximum ratings: (1)Power source voltage,VDD:-0.5 to 7.0V; (2)Input voltage ,VIN:-0.5 to VDD+0.3V; (3)Storage temperature,TSTG:-55 to +125°C; (4)Soldering condition, TSOL:Twice at under +260 °C within 10s orunder +230 °C within 3min.
Features
RTC-64613A features: (1)Built-in crystal unit allows adjustment-free efficient operation; (2)8-bit data bus and high speed access (85 ns Max.); (3)Provided with the same interface as S-RAM and battery backup function; (4)Interruption of alarm of sec. to day and day of week and carry interruption; (5)Reference signal selectable in a range of 1 Hz to 64 Hz (binary); (6)Leap year automatically adjustable (gregorian calendar); (7)With 1 Hz output terminal; (8)Provided with START/STOP, 30 second adjust function; (9)RTC-64613 uses a similar mounting method to that of a normal SMD IC.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 RTC64613A |
Other |
|
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
RTC64613A |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
RTC6701 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
RTC6711 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
RTC6721 |
Other |
|
Data Sheet |
Negotiable |
|
||||
